LG-BLG series semi-auto screw filling machine is designed according to the standards of Chinese National GMP. Filling, weighing can be finished automatically. The machine is suitable for packing powdery products such as milk powder, rice powder, white sugar, coffee, monosodium, solid beverage, dextrose, solid medicament, etc.
|Metering Mode||Auger rotation filling traced by weighing feedback|
|Packing Weight Range||1-500g||10-5000g|
|The screw attachment||The screw attachment|
|should be changed||should be changed|
|Filling Accuracy||±0.3-1%(According to packing weight and product specifications)|
|Power Supply||380V/220V 50-60HZ|
1. The whole machine is made of 304 stainless steel in addition to the servo motor and other accessories which completely meet the requirement of GMP and other food sanitation certification.
2. HMI using PLC plus touch screen: PLC has better stability and higher weighing precision, as well as interference-free. Touch screen result in easy operation and clear control. Human-computer-interface with PLC touch screen which have the features of stable working, high weighing precision, anti-interference. The PLC touch screen is easy to operate and intuitive. Weighing feedback and proportion tracking overcome the disadvantage of the package weight changes due to the material proportion difference.
3. The filling system is driven by servo-motor which have the features of high precision, large torque, long service life and the rotation could be set as requirement.
4. The agitate system assemble with the reducer which is made in Taiwan and with the features of low noise, long service life, maintenance-free for all its life.
5. Maximum 10 formulas of products and adjusted parameters can be saved for later using.
6. The cabinet is made in 304 stainless steel and fully closed with visual organic glass and air-damping. The activity of the product inside the cabinet could be seen clearly, the powder will not leak out of the cabinet. The filling outlet is equipped with the dust-remove device that can protect the environment of the workshop.
7. By changing the screw accessories, the machine can be suitable for multiple products, no matter super fine power or large granules.
Terms of Payment:
30% deposit by T/T when confirming the order，70% balance by T/T before shipping. Or irrevocable L/C at sight.
12 months after B/L date.
